Description

🔹 MULTISPAN MDT-2312N – Key Specifications

The model and key specifications above are supported by Multispan’s documentation and current product information; the official Multispan site also lists the 72 × 72 × 45 mm MDT-2312F variant with closely corresponding specifications.

⚙️ Main Features

1. Easy Thumbwheel Setting
The required timing value can be set conveniently using the front thumbwheel arrangement.

2. Multiple Time Ranges
The timer supports selectable second/minute ranges, making it useful for different machine-control requirements.

3. Delay ON / Delay OFF
The operating mode can be configured for delayed switching applications.

4. Relay Output
The timer provides a 1 Relay, 2 C/O output configuration, suitable for controlling external circuits within the specified rating.

5. Industrial Panel Application
Its compact panel-mounted format makes it suitable for control panels and machine automation.

🏭 Applications

MULTISPAN MDT-2312N can be used for:

• Industrial Automation Panels
• Machine Control Panels
• Control Panels
• Packaging Machines
• Conveyor Systems
• Motor Control Applications
• Material Handling Machines
• Process Automation
• Textile Machinery
• Electrical Control Systems
• Sequential machine operations
• Delayed ON/OFF control

Multispan categorizes its thumbwheel timers for easy delay ON/OFF timing applications and lists applications across industrial automation and machinery.

🔧 Why Use a Digital Timer?

A digital timer can help automate operations that require a defined time delay instead of manual switching. For example, a machine sequence can be designed so that a relay operates after a preset time or remains active for a defined period, depending on the configured operating mode.

This makes timers useful in machine sequencing, conveyor control, pump-related control logic and other panel applications.

📌 Ordering / Model

MULTISPAN MDT-2312N-A2-00
Auxiliary Supply: 100–270V AC
Output: 1 Relay, 2 C/O

For quotation purposes, you can write:

MULTISPAN MDT-2312N-A2-00 Digital Timer, 3-Digit Display, Thumbwheel Setting, 100–270V AC Supply, 1 Relay 2 C/O Output, Multi-Range Sec/Min.
